SmartFly™ Yoke

389.00$

SmartFly Yoke

Salient Features

  • Stainless steel shaft, Precision Machined core for stable and rugged operation
  • Advanced Hall Effect ratiometric non-contact sensors for both Pitch and Roll axis resulting in high precision output
  • Progressive damping to ensure a realistic resistive feel during operation
  • Plug and play in PC
  • All metal construction powder coated enclosure
  • Dual rail advanced linear guide with machined stainless steel shaft for extra smoothness and precise operation
  • Yoke handle designed in aluminum for rugged operations with rugged switches
  • Ergonomically designed handle to feel a realistic flying.
  • 2-Push button,2-Paddle rocker switch & 8 way Hat switch
Category: Product ID: 3823

Description

Designed from ground up with years of experience in design and manufacturing GA flight simulators.

Our Yokes provide the next immersive step beyond the joy sticks for flight simulators.

The SmartFly Yoke-I series solid metal Pro grade construction has been designed from the ground up as reliable, easy to use flight simulation devices that offer the high degree of precision and accuracy required for realistic training. We can say it as <<< Next to Reality >>>

Tech Specifications

Description

Tech details

Compatible Simulation Software

FSX / MFS2020/ P3D / X-Plane / Other USB supported simulations*

Yoke Handle

Aluminum with high gloss finish

Shaft

Custom Machined Stainless steel

Core base Rail

Hardened steel dual rail linear guide bearing

Pitch Travel

150mm (75+75mm)

Roll Rotation

160 deg (80+80 deg)

Data cable

USB

Sensor’s

For both Pitch and Roll - Linear hall effect ratiometric analogues

Dimensions / weight

7Kgs / 15.4 Lbs

Maintenance

Dry bearings results in virtually zero maintenance

Construction

Enclosure : Mild steel with black matte powder coat finish

Accessory

Fixing C Clamp-2nos / USB Cable (1.5m) / Quick start guide / 1no-Bungee rope set/ Direct mount template drawing
